ARMOURED FIBRE PATCH CORD
ARMOURED FIBRE PATCH CORD WITH STEEL-TUBE PROTECTION FOR INDOOR LINKS REQUIRING ADDED CRUSH AND RODENT RESISTANCE.- Configuration
- CONFIGURED TO ORDER
ConfigurationCONFIGURED TO ORDER
CategoryFibre Patch Cords
Decision pathSpecifications + host + evidence
Key specifications
Fibre modesOS2 / OM1 / OM2 / OM3 / OM4
Fibre countSimplex / duplex / 12 fibres
Connector optionsLC / SC / ST / FC / LSH / MTP
Cable diameter3.0 mm
Insertion loss≤ 0.3 dB
Return lossSM UPC ≥ 50 dB; SM APC ≥ 60 dB; MM UPC ≥ 30 dB
Operating temperature-25°C to +70°C; MTP armoured: -20°C to +60°C
Storage temperature-25°C to +70°C; MTP armoured: -20°C to +85°C
Buyer guidance
Mechanical protectionA stainless-steel tube and aramid strength member add protection while retaining cable flexibility.
Configuration rangeChoose fibre mode, fibre count, connector pair, polish, jacket and length.
Route planningConfirm the dynamic and static bend requirements before installation.
Connector handling
Clean, orient and install the connector correctly.
LC, SC, ST and FC connectors use different latch or coupling methods. Keep protective caps fitted until use, inspect the end face and avoid touching the ferrule.
Transmission planning
Use fibre grade and interface together.
Representative distances from the supplied patch-cord guide are shown below. The transceiver specification, installed link loss and applicable Ethernet standard remain authoritative.
Swipe horizontally to see all columns.
| Rate | Interface | Fibre | Wavelength | Maximum distance |
|---|---|---|---|---|
| 1G | 1000BASE-SX | OM1 | 850 nm | 275 m |
| 1G | 1000BASE-SX | OM2 / OM3 / OM4 | 850 nm | 550 m |
| 1G | 1000BASE-LX | OS2 | 1310 nm | 10 km |
| 10G | 10GBASE-SR | OM1 / OM2 / OM3 / OM4 | 850 nm | 33 / 82 / 300 / 400 m |
| 10G | 10GBASE-LR | OS2 | 1310 nm | 10 km |
| 40G | 40GBASE-SR4 | OM3 / OM4 / OM5 | 850 nm | 100 / 150 / 150 m |
| 40G | 40GBASE-LR4 | OS2 | 1310 nm | 10 km |
| 100G | 100GBASE-SR4 | OM3 / OM4 / OM5 | 850 nm | 70 / 100 / 100 m |
| 100G | 100GBASE-LR4 / ER4 | OS2 | 1310 nm | 10 / 40 km |
Compatibility matching
Compatible with a wide range of major network brands.
Send the host device brand, model and link requirements so we can match an appropriate option.Applications
Review where this product fits the link design.
Confirm the host port, fibre or cable path, distance and operating environment before selecting the final variant.
- Protected indoor routesPatch leads exposed to handling, abrasion or tighter equipment spaces.
- Equipment roomsConnections requiring more mechanical protection than a standard patch lead.
- MTP/MPO assembliesArmoured multi-fibre options for applicable configurations.
Testing evidence
Request evidence against the exact product scope.
Available evidence depends on the model and agreed review scope. Ask for the checks needed by engineering or procurement before approving a sample or rollout.
- Product identityModel, label, connector and wavelength details
- Host contextCoding or recognition evidence where applicable
- Output evidenceOptical, diagnostic or link information where available
Product datasheets
Review the document for the exact model.
Review the document for the exact model and reach before approving a sample or rollout.
Request the current datasheetRelated questions
Five answers for this product path.
Product selectionHow do I confirm the connector requirement?
Check the module receptacle and the existing cabling plan. Duplex LC, simplex LC, MPO/MTP and copper interfaces require different patching and polarity arrangements, so the connector should be confirmed before quotation.
Browse productsCompatibility & codingWhat information is required for a compatibility review?
Provide the equipment manufacturer, exact device model, firmware or network OS, port role, requested data rate and any OEM module reference. These details allow a model-specific review instead of a brand-level assumption.
Start a model reviewOptical link designHow can connector cleanliness affect a link?
Dust or damage can increase loss and reflection, causing low receive power or an unstable link. Inspect and clean connectors using an appropriate process before replacing working equipment.
Use the selection guideHigh-speed deploymentHow do I choose between parallel and duplex high-speed optics?
Compare the host-supported standards, installed fibre, connector, reach and migration plan. Parallel optics often use MPO/MTP; duplex solutions use LC but may have different optical and FEC requirements.
Plan a technical reviewDocuments & procurementWhat should be checked on a quotation?
Confirm the product code, variant, quantity, compatibility scope, document requirements, delivery basis, price validity and any sample or acceptance conditions before placing an order.
