WDM SFP, BIDI SFP transceiver, Simplex SFP - Max 160km on 1.25G BIDI SFP
Astra Photon 1.25G BIDI SFP, is 100% compatible with over 150 brands equipment in the market.Such as Cisco, HP, HUAWEI & etc with maximum 160km transmission.
Product codeAP-SG-SMS-3
CategorySFP Transceivers
Document pathDatasheet + compatibility review
Key specifications
Vendor NameAstra Photon
Form TypeBIDI SFP
Data Rate1.25Gbps
Wavelength1310/1550NM,1490/1550NM
Reach3~180KM
Optical InterfaceSC/LC
Media TypeSM
DDM SupportOptional
Commercial Temp.0~70℃
Industrial Temp.-40~85℃
Compatible BrandsCisco,HP,Huawei,etc...
CertificatesCE,FCC,ROHS,REACH
HS Code8517706000
Warranty3 Years
Buyer guidance
1.25G data rate
BIDI SFP package with SC/LC connector
1310/1550nm,1490/1550nm FP/DFB laser
From 3km MM to 180km SM transmission on SMF
+3.3V single power supply
LVPECL compatible data input/output interface
Low EMI and excellent ESD protection
laser safety standard IEC-60825 compliant
